3. Balancing Procedures
3.1. Wheel Lift Operation
Raising the Wheel Assembly
CAUTION
When operating the wheel lift, make sure to maintain two-handed control of the wheel assembly.
Slide the appropriate Bullseye™ Centering System collet onto the spindle shaft.
1. Position wheel lift carriage at the end of the wheel lift rail.
2. Press the lift control handle “down” until the trolley carriage is at its lowest level.
3. Roll the wheel assembly onto the wheel lift carriage.
4. Raise the lift control handle “up” to move the lifting assembly into a position where the wheel assembly can be
installed onto the spindle shaft.
5. Slide the tire/wheel assembly onto the spindle and center on the collet. Verify that the wheel assembly is centered
vertically on the spindle shaft.
NOTICE
Lower wheel lift as needed to clamp wheel, but keep the wheel lift carriage in place under the wheel
assembly.
6. Clamp wheel onto the spindle shaft.
7. Keep the wheel lift carriage in place under the wheel assembly and close the hood. The lifting assembly will
automatically lower and park the carriage below.
NOTICE
Allowing the balancer to park the wheel lift carriage in place under the wheel assembly will make the
removal and lowering of wheel assembly easier and quicker.
Lowering the Wheel Assembly
1. Remove the clamp
2. Starting with the wheel lift carriage parked under the wheel assembly; raise the lift control handle “up” to move the
lifting assembly to the wheel assembly.
3. Release the lift control foot pedal when the assemblies contact one another. Remove the wheel clamp
4. Slide the carriage with wheel assembly to the end of the wheel lift rail.
5. Press the lift control handle “down” until the carriage is at its lowest level. Roll wheel assembly from carriage.
3.2. CenteringCheck® & Collet Mounting
CenteringCheck® is an inspection or verication of the wheel’s mount to balance to identify possible centering errors, thus
recognizing improper measurements.
From the main balance screen, touch the “CenteringCheck” button and follow the on-screen instructions.
FRONT / BACK COLLET MOUNTING
