Probe Head Replacement Procedure
7. Probe Head Replacement Procedure
• Case splitter part number 6AE025 (not required for D920-P, D930-P, FD1-P & FD3-P).
• 20MHz Oscilloscope (Gould OS300 or equivalent) and x10 probe.
• Plastic jawed vice.
• DVM on current range (for specification see Appendix D).
• Synthesised signal generator (for specification see Appendix D).
• Head alignment service kit, part number 6AH072.
• Frequency counter (for specification see Appendix D).
• Soldering iron (for specification see Appendix A).
• New case halves, part number 6AE114.
• Power supply (for specification see Appendix D).
7.1 Equipment Required
SPECIAL
HANDLING
PROCEDURES
Thhee
PCB
aasseembblliiees
useedd
iin
thhee
maaiin
uniit
aandd
proobbee
ccoontaaiin
eelleecctroostaatiicc
ddeeviiccee
(ESD).
Thheesee
maay
bbee
peermaaneentlly
ddaamaageedd
bby
eelleecctroostaatiicc
pooteentiiaalls
eenccoounteereedd
iin
rooutiinee
hhaanddlliing
oof
thhee
aasseembblliiees
dduriing
seerviicciing.
WWee
thheereefooree
reeccoommeendd
thhaat
aallll
seerviicciing
bbee
ccaarriieedd
oout
iin
aa
speecciiaalliiseedd
hhaanddlliing
aareeaa,
(SHA)
aas
ddeefiineedd
bby
CECC00015
too
aavooiidd
ddaamaagee
too
thhee
aasseembblliiees.
The retractile cable must be disconnected from the control unit before head replacement can
begin (see section 6.3).
A spare retractile cable or the retractile cable from the unit must be disconnected from the
control unit before a head replacement can begin.
7.2 Preparation - For High Sensitivity Probes OP2HS, OP3HS, VP4HS,
VP5HS, VP8HS, VP10HS, EZ8)
