General Information
The FD1-P and D920-P have dedicated 2MHz probes that are hard wired via a retractile cable.
The FD3-P and D930-P have a dedicated 3MHz probe that is hard wired via a retractile cable.
Miinii Doopplleex (D900-PP)
is primarily a vascular unit with a non-directional waveform output.
The Mini Dopplex accepts the obstetric probes, providing audio
only output.
Feetaall Doopplleex II (FD22-PP)
has interchangeable probes accepting the full range of obstetric
and vascular probes, although it is primarily a Fetal Dopplex with a
heart rate display. Using the vascular probes, only audio signals
are available and there is no rate counting facility, or waveform
outputs.
Supeer Doopplleex II (SD22-PP)
is a dedicated vascular Doppler with all the vascular functions of
the MD2-P, but without the RS232 waveform output.
Mulltii Doopplleex II (MD22-PP)
is a multi-purpose Doppler with bi-directional waveform and stereo
headphone outputs. Graphical representation of velocity waveforms
is given by the LCD display. The same obstetric features of the
FD2-P are incorporated into the MD2-P.
Auddiioo Doopplleex (D9220-PP
are dedicated obstetric Dopplers with fixed waterproof 2MHz
D9330-PP)
(D920-P) and 3MHz (D930-P) probes.
Aqquaa Doopplleex Pllus (FD1-PP)
is derived from the FD2-P, but has a hardwired waterproof 2MHz
probe.
FD33-PP
is derived from the FD2-P, but has a hardwired waterproof 3MHz
probe.
Rhheeoo Doopplleex II (RD22)
has the vascular functions of the MD2-P with the addition of a
Photoplethysmographic sensor.
For further details on the controls of the D900-P, D920-P, D930-P, FD2-P, SD2-P, MD2-P, FD1-P,
FD3-P and RD2 units, please refer to the user manuals.
Due to the nature of the components used within the D900-P, D920-P, D930-P, FD2-P, SD2-P,
MD2-P, FD1-P, FD3-P and RD2 units, special precautions must be taken to avoid damage to
the CMOS and microcontroller based circuitry. Static damage may not be immediately evident
but could cause premature failure.
This series of units must only be dismantled and serviced within a specialised handling area
(SHA) as defined by CECC00015 (published by CENELEC) to avoid damage to the assemblies.
1.4 Antistatic Handling
The control unit comprises a single PCB on which all circuitry and electro-mechanical
components are mounted directly except for the loudspeaker which is attached by flying leads.
A hard wired cable provides the connection to the probe.
The PCB has surface mounted components on both sides. All leaded and electro-mechanical
components are on one side.
All electro-mechanical and through hole components on the control PCB are serviceable using
standard tools and soldering techniques, provided that anti-static precautions are always
observed.
The case of the control unit is moulded in ABS polycarbonate alloy, and comprises two halves.
The loudspeaker, on/off switch and display are on the front of the unit.
1.5 Construction
