GENERAL
TRANSMISSION
Multi-plate clutch in oil bath, hydraulic control
5-speed (TC) or 6-speed (TE-SMR-TXC) gearbox, constant mesh gear type
Drive between engine and gearbox main shaft by straight toothed
Primary drive
Drive pinion gear (TC 250) ............................................. z 20
Drive pinion gear (TE-TXC 250, TE 310) ....................... z 24
Drive pinion gear (450-510) ........................................... z 23
Clutch ring gear (TC 250) .............................................. z 67
Clutch ring gear (TE-TXC 250, TE 310) ........................ z 88
Clutch ring gear (450-510) ............................................. z 63
Transmission ratio (TC 250) ......................................... 3.350
Transmission ratio (TE-TXC 250, TE 310) ................... 3.666
Transmission ratio (450-510) ....................................... 2.739
Gearbox ratios (TE-SMR-TXC)
1st gear .......................................................... 2.000 (z 28/14)
2nd gear ......................................................... 1.611 (z 29/18)
3rd gear ......................................................... 1.333 (z 24/18)
4th gear .......................................................... 1.086 (z 25/23)
5 th gear ........................................................ 0.920 (z 23/25)
6 th gear ........................................................ 0.814 (z 22/27)
Gearbox ratios (TC)
1st gear ....................................................... 1.866 (z 28/15)
2nd gear (250) .............................................. 1.529 (z 26/17)
2nd gear (450-510) ....................................... 1.444 (z 26/18)
3rd gear.......................................................... 1.263 (z 24/19)
4th gear ......................................................... 1.086 (z 25/23)
5 th gear ......................................................... 0.954 (z 21/22)
Final drive
Drive between gearbox and rear wheel by 5/8" x 1/4" chain (with OR for TE, TXC and SMR models).
Transmission sprocket (TE 250-310-450-510; TXC 250-450-510) ................. z 13
Transmission sprocket (TC 450) ...................................................................... z 14
Transmission sprocket (TC 250) ...................................................................... z 12
Transmission sprocket (TC 510) ...................................................................... z 14
Transmission sprocket (SMR 450-510) ........................................................... z 14
Rear wheel sprocket (TE 250-310 TXC 250) ................................................... z 50
Rear wheel sprocket (TC 450) ......................................................................... z 50
Rear wheel sprocket (TC 250) ......................................................................... z 50
Rear wheel sprocket (TC 510 TE 450-510; TXC 450-510) ............................. z 47
Rear wheel sprocket (SMR 450-510) ............................................................... z 42
Transmission ratio (TE 250-310) ................................. 3.846
Transmission ratio (TE 450-510) ................................. 3.615
Transmission ratio (TC 250) ........................................ 4.166
Transmission ratio (TC 450) ........................................ 3.571
Transmission ratio (TC 510) ........................................ 3.357
Transmission ratio (SMR 450-510) ............................. 3.000
Rear chain size ........................................................ 5/8”x1/4”
