Husqvarna 2009 TE 310 - Fitting the Fork Back on Themotorcycle

I.22
Part. N. 8000 H0368 (09-2008)
FRONT SUSPENSION
FITTING THE FORK BACK ON THEMOTORCYCLE
WARNING
Fit the fork back onto the frame following the instructions in the motorcycle
manufacturer’s manual, as for the steering elements, brakes and wheel. The
incorrect assembly of these elements can be dangerous for the rider.
For the fork to work correctly, the wheel must be installed on the fork as follows:
• Insert the axle through the right wheel axle clamp, the wheel and the left wheel axle
clamp.
• Screw down the nut on the left side of the axle and tighten fully.
• Fully compress the fork a few times.
• Tighten the two bolts on the right wheel axle clamp following the sequence 1- 2- 1.
