E.2 Part. N. 8000 H0364 (09-2008)
GENERAL OPERATIONS
FOREWORD ............................................................ E. 3
REMOVAL OF ENGINE FROM MOTORCYCLE ...... E. 4
PARTIAL DISMALTEMENTS
Removal of saddle and battery .................................. E. 15
Removal of side panels ............................................. E. 16
Removal of rear frame with fender
(TE- SMR: with tail light) and air filter box assy .......... E. 17
Removal of exhaust system ...................................... E. 20
Removal of fuel tank, conveyors and spoiler ............. E. 23
Removal of cooling fan (TE-SMR), radiators and
coolant expansion tank (TE-SMR) ............................ E. 25
Removal of electronic power unit C.D.I.,
electronic coil, voltage regulator and clutch hose ....... E. 26
Removal of secondary drive chain ............................ E. 26
