H.30 Part. N. 8000 H0368 (09-2008)
ENGINE REASSEMBLY
Reassembly of flywheel
Clean the flywheel rotor removing any debris gathered in centrifugated oil and
attracted to the magnets. Reassembly the Woodruff key and the rotor on the
crankshaft. Holding the rotor (on the R.H. side place an aluminium shim between
the teeth of the primary drive gears, in order to prevent its rotation), mount the nut
and tighten it to 75 Nm-7,65 Kgm- 55.3 ft/lb. Mount the two centering bushes.
