J.17
Part. N. 8000 H0368 (09-2008)
REAR SUSPENSION
1- Chain tension roller
2- Chain driving roller
3- Chain guide
4- Chain slider
a- Joint spring
Chain tension rollers, chain driving roller, chain guide, chain runner
Check the wear of the above mentioned elements and replace them when
necessary.
: Check the chain guide alignement, and remember that a bent element can
cause a rapid wear of the chain. In this case, a chain fleeting from the sprocket may
ensue.
TE-TC-TXC-SMR
