H.5Part. N. H0368 (09-2008)
ENGINE REASSEMBLY
Tightening torques
7 M14x1 (+LOCTITE 243) 20 Nm- 2 Kgm- 14.5 ft/lb
11 M6x1 11 Nm- 1,1 Kgm- 7.9 ft/lb
12 M16x1,5 25 Nm- 2,55 Kgm- 18.4 ft/lb
13 M14x1,5 25 Nm- 2,55 Kgm- 18.4 ft/lb
16 M12x1 75 Nm- 7,65 Kgm- 55.3 ft/lb
17 M6x1 (+LOCTITE 272) - TC, TXC 8 Nm- 0,8 Kgm- 5.8 ft/lb
M5x0,8 (+LOCTITE 272) - TE, SMR 6 Nm- 0,6 Kgm- 4.3 ft/lb
19 M5x0,8 (+LOCTITE 272) 6 Nm- 0,6 Kgm- 4.3 ft/lb
LUBRICATING POINTS-NOTES LUBRICANT-INSTRUCTIONS FOR ASSEMBLY
A Degrease
B Mount with Engine oil
C Glue the two half casings by “Loctite 510" (Pianermetic)
E Align the stator notch to the notch on the stator cover
G Grease WATER RESISTANT
O Engine oil
O/G Engine oil or grease WATER RESISTANT
STANDARD
M5x0,8 6 Nm- 0,6 Kgm- 4.3
ft/lb
M6x1 8 Nm-0,8 Kgm- 5.8 ft/lb
M8x1,25 21 Nm- 2,1 Kgm- 15.5 ft/lb
