H.14 Part. N. 8000 H0368 (09-2008)
ENGINE REASSEMBLY
Reassembly of crankshaft
Carefully clean the lubrication ducts. Lubricate the crankpin with motor oil and
place it in the flywheel.
Fit the roller bearing and lubricate with engine oil. Fit the connecting rod and the
second half-flywheel. See that the half-flywheels are aligned using a triangle.
Join all the elements using a press.
Press the crank discs together to the same distance as the length of the
crankpin. Respect measure “B” shown on page H.15 when fitting the coupling pin.
