H.37Part. N. H0368 (09-2008)
ENGINE REASSEMBLY
Assembly of valve lifter
Mount the valve lifter in the head and, turning it in lift position, insert the retaining pin.
Reassemble the lubrication tube.
Lubricate the cammes abundantly with motor oil.
Reassemble the four U-bolts for fixing the camshaft and tight the screws to 12 Nm-
1,2 Kgm-8.7 ft/lb.
