M.47Part. N. 8000 H0368 (09-2008)
ELECTRIC SYSTEM, DIGITAL INSTRUMENT
• Connecting the MAQS connector
Connect the MAQS connector as shown.
• Connecting the engine water temperature connector
Connect the engine water temperature connector as shown.
• Posiotioning the lambda sensor
Screw the lambda sensor as shown.
• Connecting the lambda sensor connector
Connect the lambda sensor connector as shown.
