O.21Part. N. 8000 H0368 (09-2008)
“KIT” ASSEMBLING INSTRUCTIONS
Pour the proper oil amount in the crankcase (1,5 l.-1.3 Imp. Quarts- 1.6 U.S.
Quarts of AGIP RACING 4T/ 10W-60). Reassemble the rear brake control pedal
(6 mm allen wrench; tighten fastening bolt at 42 Nm-4,2 kgm-31ft/lb+LOCTITE
243). Check that O-Rings are in place. Check the brake fluid level (A) in the
tank. Connect the battery to electric system (E.15) and test kick start pedal (42).
A
42
