O.25
Part. N. 8000
H0368
(
09
-2008)
“KIT” ASSEMBLING INSTRUCTIONS
Loosen the nuts of the throttle cables.
Remove the throttle cables from their housings.
Loosen both screws fastening the pulley locking plate.
Remove the locking plate.
