24 Excelon Operator’s Manual
[Connecting the Water Drain Hose] [ Connecting the Water Supply Hose ]
Fixing Clip for Water Drain Hose
• Fill up 2/3 of the tank with water and make sure that the water supply hose is
not dragged below the pump, and is not folded or interfered with other objects.
• Use the Clip to tie the Water Supply Hose properly.
4.2 Frame Reader
① Remove the shock-absorbing material from the packing box and pull out the
Frame Reader carefully.
② Remove the shock-absorbing material from the workspace of Stylus.
③ Plug the Power Cable into the receptacle at the back of the product and turn on
the power to check the initial operation.
④ If the initial operation works properly, connect Edger and Frame Reader by using
9-pin D-sub Crossed Interface Cable.
