Huvitz Excelon - 5.4 Edging Process; 5.4.1 Preview MODE

36 Excelon Operator’s Manual
Edger Control Panel
STOP
One Stop Edging Execution
• Be sure that Lens Position Button only works during Roughing process. It is
useful to adjust the lens position if the lens exceeds the wheel range because
of the thickness.
• Clamp Buttons in the Left and Right provide the exactly same function. They
are provided for the convenience to press the button by the bare hand without
holding the lens.
LENS POSITION
Button for adjusting the Lens
Position in Roughing Process
(Real Time)
!
NOTE
CLAMP
START
CLAMP
