Excelon Operator’s Manual 77
a. The movement of beveled position
Fron t Rea r
-
-
+
+
+
+
-
-
Lens
Pos ition
Bevel
Pos ition
b. The effect of adding (-) value for the beveled position
After adding (-) Bevel Position Value
c. The movement of polishing in bevel process
Rear
+
+
Lens
Position
-
-
Lens
Position
Front
d. The effect of adding (-) for the polished position in bevel process
After adding (-) P olish Bevel V alue
