139
7. Alarm List
Alarm
No.
Alarm Picture Cause Action
39
Push bar too long.
When new bar goes to
part off with turret
position , barfeeder send
M code finish signal to
lathe , then turret is
moving , but the pushrod
is moving over the
spindle length
Check CNC program
(on 4.8)
40
(Normal barfeeding jobs)
EOB value setting too long
When you select normal
feeding jobs function ,
Pushrod push the bar
over than S value
(spindle length),
Setting
EOB (End of bar position )
= S value(spindle length)
– W value(component
length)
41
Pushrod can’t return to home
position
When you select normal
feeding jobs function ,
Pushrod push the bar
over than S value
(spindle length).
Setting
EOB (End of bar position )
= S value(spindle length)
– W value(component
length)
To Next Page
