Hydrafeed MSV 65 - Page 185

182
1
3
2
45678
A
B
C
D
E
F
G
H
Model
Weight
Quantity
Unit：mm
Name
Date
Revision
Part No.
Draw
Material
Scale
Page
1
1 / 1
>400....±0.8
120-400....±0.5
30-120....±0.3
6-30....±0.2
3 - 6 . . . .
±
0 . 1
< 3 . . . .
±
0 . 1
G e n e r a l
T o l e r a n c e
A3
Dean
S24201-002X
S65
Transmission unit - 1200
1:7
2017/12/20
A
15
18
4
11
10
2
12
7
9
14
6
8
3
13
5
16
17
Q'ty
Part Number
Item
1
S04801-000X
1
1
S04802-000X
2
1
S04803-000X
3
1
S11123-002X
4
1
S14205-002X
5
2
S14206-000X
6
1S14701-002X
7
1
T04201-000X
8
1
T04301-000X
9
1
T07100-1802
10
1
T14501-001X
11
1
T17100-1840
12
6
Hex socket cap screws-SW Set[M10x1.5x25L]
13
4
Hex socket cap screws-SW Set[M6x1.0x12L]
14
8
Hex socket cap screwsSSet[M6x1.0x12L]
15
31
Hex socket cap screws[M5x0.8x20L]
16
31
NutSWSet[M5x0.8]
17
8
Washer[6x19x1.5]
18
T07100-1902
(dia:19mm Black pushrod)
T17100-1940 (hole dia : 19mm
bush for dia:19mm Black pushrod)
