Hydrafeed MSV 65 - Page 190

187
1324
5
678
A
B
C
D
E
F
G
H
Model
Weight
Quantity
Unit：mm
Name
Date
Revision
Part No.
Draw
Material
Scale
Page
1
1 / 1
>400....±0.8
120-400....±0.5
30-120....±0.3
6-30....±0.2
3 - 6 . . . .
±
0 . 1
< 3 . . . .
±
0 . 1
G e n e r a l
T o l e r a n c e
A4
Rolly
S04802-000X
S65
Long arm set
1 : 2
2015/5/28
A
Q'ty
Part Number
Item
1
S14816-000X
1
1
T15106-000X
2
1
Hex socket cap screws-SW Set[M6x1.0x20L]
3
2Hex socket cap screws-SW Set[M6x1.0x25L]
4
4
Hex socket cap screws-SW Set[M8x1.25x25L]
5
1
Nut[M8x1.25]
6
1
Washer[8.4x30x3.0]
7
3
Set Screw[M6x1.0x12L]
8
1
Set Screw[M8x1.25x30L]
9
8
21
5
6
9
7
4
3
