Hydrafeed MSV 65 - Page 191

188
1
3
2
4
5
678
A
B
C
D
E
F
G
H
Model
Weight
Quantity
Unit：mm
Name
Date
Revision
Part No.
Draw
Material
Scale
Page
1
1 / 1
>400....±0.8
120-400....±0.5
30-120....±0.3
6-30....±0.2
3 - 6 . . . .
±
0 . 1
< 3 . . . .
±
0 . 1
G e n e r a l
T o l e r a n c e
A4
Rolly
S04803-000X
S65
1 : 2
2015/5/28
A
Q'ty
Part Number
Item
1
P+F[NBB2-12GM40-E0-5M]
1
1
S14817-000X
2
1
S14822-000X
3
2
T15110-000X
4
1
T15121-000X
5
1
T15122-000X
6
2
T19109-000X
7
4
Hex socket cap screws-SW Set[M6x1.0x45L]8
4
Hex socket cap screws-SW Set[M8x1.25x25L]
9
1
Hex socket cap screws[M6x1.0x12L]
10
3
Set Screw[M6x1.0x5L]
11
2
Set Screw[M6x1.0x6L]
12
8 6
1 2
4
4
9
7
12
5
11
3 10
