PARTS LIST
6-12 HT4400 Instruction Manual
4-00
Consumable Parts Kit
Part
Number Description Qty.
128497 Consumable Parts Kit
001067 Box:Gray Plastic 1
004663 Nozzle Wrench 1
026009 O-ring, .208 x .070 5
027012 Lubricant:Silicon 2-Oz Tube 1
027102 Electrode Wrench 1
027347 Tool: Water Tube Replacement 1
044028 O-ring, 1.364 x .070 2
120025 Water Tube 1
120777 Nozzle Assy:100A Oxygen cw 3
120783 Swirl Ring:100A Oxygen cw 1
120785 Electrode:100A Oxygen 3
120786 Cap:Nozzle Retaining 1
120787 Nozzle Assy:200A Oxygen cw 3
120791 Swirl Ring:200A Oxygen cw 1
120793 Electrode:200A Oxygen 3
120794 Nozzle Assy:300A Oxygen cw 6
120800 Swirl Ring:400A Oxygen cw 1
120802 Electrode:300A Oxygen 3
120804 Assy:400A Oxygen cw 3
120810 Electrode:400A Oxygen 3
120853 Swirl Ring:200A/400A Nitrogen cw 2
120855 Electrode:200A/400A Nitrogen 6
120856 Nozzle Assy:400A Nitrogen cw 3
120913 Swirl Ring:300A Oxygen cw 1
See Consumable Configurations earlier in this section for graphics and proper
combinations of consumables.
Counterclockwise Consumables
Oxygen 400 amp 300 amp 200 amp 100 amp
Swirl Ring 120940 120914 120792 120784
Nozzle 120935 120795 120788 120788
Nitrogen 400 amp 300 amp 200 amp 100 amp
Swirl Ring 120854 120854
Nozzle 120857 120795
