Hypertherm Koolant Koolers N-Series User Manual

 Introduction‐RatedCapacity
9
4 Introduction
TheKoolantKoolersIndoorIndustrialProcessChillerisasingle‐circuit,singlereservoirchillerdesignedto
supplycoolanttotheHy pertherm Plasma CuttingSystem.Heatremovalfromtheplasmacuttingsystemtothe
chillerisfacilitatedthroughheatexchangersinaclosed‐loopfashionusinganair‐cooledrefr igerationcircuit.
Thechill
eriscapableofsteadilysupplyingcoolantwithtighttemperaturetolerancesoveravaryinganddynamic
rangeofcoolingcapacityrequirem ents. Thechillerfeatures:
 ScrollCompressor
 Provenreliability
 Lownoise
 Processcircuitregenerativeturbinepump
 Highlyreliable(noslidingcomponents)
 Optimizedforhighpressurecircuits
 Recirculationcircuitcentrifugalpum
p
 Moderatesthereturncoolanttemperaturefromtheplasmacutterpriortopassing throughthe
brazedplateheatexchanger
 Highlyreliable(noslidingcomponents)
 Variablespeedcondenserfan
 Minimizesacousticnoise
 Improvedenergyefficiency
 Managesrefrigerationsuctionpressureunderlowam
bienttemperatures
 Continuouscoolantreservoirlevelsensing
 Provideslowreservoirwarnings
 Preventspumpsfromrunningdry
 Process&recirculationflowsensing
 Protectspumpsfromrunningdry
 Supportspropersettingofthrottlingandreliefvalves
 Refrigerationpressureandtemperaturesensors
 Enablethesuctionanddischargecondi
tionsoftherefrigerationcircuittobemonitoredbythe
controller
 Enablethecontrollertocalculatesuperheatandsubcoolingconditionstosupportremote
troubleshooting
 Remotemonitoringandcontrolcapabilities
 Plug‐and‐playcommunicationviaModbusEthernet
 Built‐inwebserverfordataloggingandremotemonitoring


Hypertherm, Inc. Part Number: 810540
