8.7 Setpoints
Thesescreensdisplaytheusersettablesetpointsforthechiller.

Figure30:Setpoints,Temperature
TemperatureSetpoint:Outlettemperature
setpointfortheprocesscoolingwater .
UnitsofMeasure:Selecttheunitsofmeasure
tobedisplayedontheuserinterface.

Figure31:Setpoints,PlasmasystemOutletFlow
Fluid:HeatTransferFluidtype.
Concentration:PercentageofHeatTransfer
Fluidvs.water.
OperatingFrequency:Frequencyof mains
power.



Figure32:Setpoints,StandbyMode
Enable:StatusofStandbyModeoperation(YES
=enabled,NO=disabled).
StandbyModeSetpoint:Minimumallowable
processcoolanttemperaturewhenStandby
Modeisenabled.


