 Controller‐Monitoring 
34

Figure16:Monitoring,ProcessFluidCircuit
DisPress:Measuredsupplypressureofcold
watercircuitfromchiller.
FlowRate:Totalprocesspumpflowrate=
Plasmasystemflowrate+bypassflow rate.
TankLevel:Measuredcoolantreservoirlevel.


Figure17:Monitoring,RecirculationCircuit 
FlowRate:MeasuredInletFluidflowrate.
TankTemp:Measuredfluidtemperaturein
tank.
TankLevel:Measuredcoolantreservoirlevel.


Figure18:Monitoring,FilterStatus
InPress:InletpressuretotheFluidfilteronthe
facilityfluidcircuit. 
OutPress:Outletpressureformthefluidfilter
onthefacilityfluidcircuit.
DeltaPress:DifferencebetweentheFluid
pressureontheinletandoutletoftheFluid
filteronthefacilityfluidlo
op.
MaxDelta:Maximumdeltapressurethreshold
allowedbetweentheinletandoutletofthe
fluidfilteronthefacilityfluidloop.
FlowRate:Measuredcol dwatercircuitsupply
flowratethroughthefilter.
Hypertherm, Inc. Part Number: 810540
