8.6 Devices
Thesescreensdisplayinformationregardingthechill er’s components.

Figure20:Devices
DEVICES:Thescreensinthismenudisplay
informationregardingthechiller’s
components.


Figure21:Devices,CompressorStatus
Status:Statusofcompressor(On=running,
Off=notrunning).
CompRequired:Indicateswhetherornotthe
compressorisneededforthecurrent
operatingcondition(Off =Notrequired,On=
Required).
Abletoon(off)in:Numberofsecondsbefore
thecompressorisa
bletostartorstop.
RunTime:Totaltime(inhours)thecompressor
hasbeenoperating.
Hotgas:Percentageofhotgasvalveopen.
EEV:Percentageofelectronicexpansionvalve
open.

Figure22:Devices,ProcessPumpStatus
Status:Statusofprocesspump(On=running,
Off=notrunning).
Overload:Statusofpumpoverload(Ok=
overloadisfunctioningnormally,Fault=
overloadhastripped).
Runtime:Totaltime(inhours)thepumphas
beenoperating.

