AppendixC(DefaultControllerSettings)
65
SensorCalibration
Table13:DefaultSensorCalibrationSettings
Category Parameter Values UOM
CompressorDischargePressure
Transducer
0.5V 0.0(0.00) PSI(bar)
4.5V 500.0(34.47) PSI(bar)
CompressorSuctionPressure
Transducer
0.5V‐15.0(‐1.03) PSI(bar)
4.5V 185.0(12.76) PSI(bar)
ProcessOutletPressure
Transducer
4mA 0.0(0.00) PSI(bar)
20mA 300.0(20.68) PSI(bar)
FilterInletPressureTransducer
4mA 0.0(0.00) PSI(bar)
20mA 100.0(6.89) PSI(bar)
FilterOutletPressure
Transducer
4mA 0.0(0.00) PSI(bar)
20mA 100.0 PSI(bar)
TankLevelTransducer
4mA 0 %
20mA 100 %
RecirculationFlowMeter
4mA 0.00(0) GPM(LPM)
20mA 26.4(100) GPM(LPM)
ProcessFlowMeter
4mA 0.0(0) GPM(LPM)
20mA 5.3(20) GPM(LPM)
RecirculationTemperature
4mA 20(‐6.7) °F(°C)
20mA 150(65.6) °F(°C)
ProcessInletTemperature
4mA 20(‐6.7) °F(°C)
20mA 150(65.6) °F(°C)

Hypertherm, Inc. Part Number: 810540
