TORCH SETUP
powermax 65/85 Operator Manual 3-23
Accessing raw arc voltage
You need to connect a machine interface cable (part number 228350 or 228351) to the power
supply in order to access raw arc voltage. Refer to Field Service Bulletin 806180.
WARNING:
HIGH VOLTAGE AND CURRENT
Connecting directly to the plasma circuit for access to raw arc voltage
increases the risk of shock hazard, energy hazard, and fire hazard in the
event of a single fault. The output voltage and the output current of the
circuit are specified on the data plate.

Hypertherm Powermax 85 Specifications

General

Gas Supply	Clean, dry, oil-free air or nitrogen
Cooling Method	Fan-cooled
Input Voltage	200-600V, 3-phase
Current Output	25-85 A
Duty Cycle	60% @ 85 A
Recommended Gas Inlet Flow Rate/Pressure	6.7 scfm @ 85 psi
Cutting Capacity (Recommended)	1" (25 mm)
Gas Type	Air/Nitrogen
