speCIfICatIons
FAST Operators
1,500 lb (680 kg) gates
1 ft/s (30 cm/s)
4,000 lb (1,814 kg) gates
1 ft/s (30 cm/s)
8,000 lb (3,629 kg) gates
1 ft/s (30 cm/s)
20,000 lb (9,072 kg) gates
1 ft/s (30 cm/s)
3,000 lb (1,361 kg) gates
1.7 ft/s (50 cm/s)
5,000 lb (2,268 kg) gates
2.2 ft/s (70 cm/s) or
3 ft/s (91 cm/s)
Model SlideDriver 15 SlideDriver 40 SlideDriver 80 SlideDriver 200 SlideDriver 30F SlideDriver 50VF2/3
Part # 222 SS ST 222 E ST 222 X1 ST 444 XS ST 222 EX 1.7 ST 222 X3 ST
Gate Weight Max. 1,500 lb (680 kg) 4,000 lb (1,814 kg) 8,000 lb (3,629 kg) 20,000 lb (9,072 kg) 3,000 lb (1,361 kg) 5,000 lb (2,268 kg)
Gate Length Limited only by weight
Drawbar Pull 300 lb (136 kg) 300 lb (136 kg) 600 lb (272 kg) 1,200 lb (544 kg) 300 lb (136 kg) 300 lb (136 kg)
Rate of Travel 1 ft/s (30 cm/s) 1.7 ft/s (50 cm/s)
Field adjustable, 2.2 ft/s
(70 cm/s) or 3 ft/s (91 cm/s)
Emergency Fast Close
3 ft/s (91 cm/s)
1 Phase Power
115/208/230V 60 Hz
110/220V 50 Hz
115/208/230V 60 Hz
110/220V 50 Hz
208/230V 60 Hz
220V 50 Hz
230V 60 Hz
208/230V 60 Hz
220V 50 Hz
208/230V 60 Hz
220V 50 Hz
3 Phase Power 208/230/460/575V 60 Hz , 220/380V 50 Hz
Horsepower 1 hp 1 hp 2 hp 5 hp 2 hp 2 hp
Duty Cycle Continuous
Temperature Rating -40º F to 158º F (-40º C to 70º C) using environmentally friendly Uniow uid or -10° F to 158° F (-23° C to 70° C) using biodegradeable uid. No heater necessary.
Drive Wheels
Two 6” (15 cm)
AdvanceDrive wheels
Two 6” (15 cm)
AdvanceDrive wheels
One 8” (20 cm) AdvanceDrive
wheel, One 8” XtremeDrive
wheel and 27 ft (8 m) of rack
Two 8” (20 cm) AdvanceDrive
wheels, Two 8” XtremeDrive
wheels and 52 ft (16 m) of rack
Two 6” (15 cm)
AdvanceDrive wheels
Two 8” (20 cm)
AdvanceDrive wheels
User Controls Smart Touch Controller with 70+ congurable settings. Smart Touch keypad and display or a PC using S.T.A.R.T. software.
Relays Three congurable user relays: one 30VDC, 3A solid state and two 250VAC, 10A electromechanical
Communication RS-232, RS-485
UL 325 Listing Usage Class I, II, III, IV Usage Class I, II, III, IV Usage Class III, IV Usage Class III, IV Usage Class III, IV Usage Class III, IV
Limited Warranty 5 year
Est. Shipping Wt
96 D0559 Rev A SlideDriver/SlideDriver 50VF Series www.hysecurity.com
