56 D0559 Rev. A SlideDriver/SlideDriver 50VF Series www.hysecurity.com
Setting Performance Description Wire
Connection
7 Gate forced open output Activated if the gate is forced off the closed limit switch and
the operator is not able to restore the gate to full closed
position within four seconds.
NOTE: This alarm resets itself in 30 seconds.
Relay 1, 2 or 3
8 Gate open too long output Controls an external device. Activates when the gate is open
longer than the user-selected period of time. Adjustable
from 0 seconds with 15 to 135s selectable delay timeframes
in 30s increments.
NOTE: TL - Open TIME ALERT adjustments can be made
in the Installer Menu. The TL Installer Menu display only
appears when using this relay.
Relay 1, 2 or 3
9 Safety Mode Alert output Controls an external device. Activated when the system is
in Safety Mode or Entrapment Mode. Safety Mode occurs
when the gate encounters an obstruction. Entrapment
Mode means the gate is stopped and occurs if the internal
inherent sensor triggers while the system is in Safety Mode.
Relay 1, 2 or 3
10 Entrapment Mode Alert output Controls an external device. Activated only when in the
Entrapment Mode.
Relay 1, 2 or 3
11 Unauthorized Vehicle Entry output
(Tail gate alert)
Controls an external device. Activated when a second vehicle
enters from the outside without a valid input from an access
control device. This output releases when an access control
input signals open or the arm/gate reaches the close limit.
Relay 1, 2 or 3
12 Outside Obstruction Vehicle
Detector output
Interlocks an entry device to prevent pedestrian use. This
output is active whenever the Outside Obstruction Loop
Detector is tripped.
Relay 1, 2 or 3
13 Loitering Alert Indicates a vehicle is loitering on the Outside Obstruction
Loop. Adjustable from 0 seconds with 15 to 135s selectable
delay timeframes in 30s increments.
NOTE: LT LOITERING ALERT adjustments can be made
in the Installer Menu. The LT Installer Menu display only
appears when using this relay.
Relay 1, 2 or 3
14 Gate nearing full travel output Applies to operators with position sensors only. Activated
when the gate is 3s from expected limit switch trigger.
NOTE: If the operator has not yet learned limits, it will
energize Relay 14 when the motor begins moving the gate.
Relay 1, 2 or 3
15 Gate failure output Activated to report occurrence of a problem. Indicates
the system is in an Error Mode, Fault Mode or Entrapment
Mode.
Relay 1, 2 or 3
16 Motor Running output Active when the motor is running and gate is in motion. Relay 1, 2 or 3
17 AC Power Failure output This relay is normally energized and drops with loss of AC
power.
Relay 1, 2 or 3
18 DC Power Failure output DC operators only. The relay activates when the battery
power is very low, but the output ceases when the battery is
dead. The relay is triggered when the battery is less than 20
volts.
Relay 1, 2 or 3
19 Flasher Relay Flashes lights once per second. The relay is constantly
pulsing except when the open limit switch is triggered.
* Preferred connection is Relay 3, a solid state relay (except
on Crash operators). On Crash products, Relay 3 is hard-
wired for the LED barrier arm lights.
Relay 1 or 2*
(Relay 3)
20 Free Exit Loop Vehicle Detector
output
Active when the Free Exit Loop is tripped. Relay 1, 2 or 3
To Next Page
