MX3657-01 Rev. D ©2020
68 hysecurity.com | 800-321-9947 StrongArm Programming and Operations
Installer Menu Setting Options Menu Tasks & Explanations STC Wire
Connections
CH 0 (AC)
CHARGER TYPE
0 = AC powered charger
1 = Solar powered charger
Does not appear on an AC-powered
operator. The menu item only appears when
using the DC Charger unit and designates
the charger type.
FO 0 (DISABLED)
FIRE DEPT OPEN
0 = disabled
1 = enabled
Provides the Fire Dept. Open input. When
set to 1, the open signal received by the
operator overrides all photoelectric eyes and
edge sensors, and opens the gate. Pressing
the Open or Reset button is required before
the gate can be closed.
+24V
Fire Dept Open
(#24)
OC 0 (DISABLED)
EMERGENCY CLOSE
0 = disabled
1 = enabled
Enables the Emergency Close input. When
set to 1, the constant hold close overrides
vehicle detectors, photo eyes and edge
sensors, and closes the gate. Pressing the
Reset button once or the Open button twice
is required before the gate will open.
+24V
EMERG CLOSE
(#23)
SE 2
IES SENSITIVITY
(Not used in
StrongArm models)
1 = maximum sensitivity
2 = moderate (default)
9 = lowest sensitivity
Adjusts the sensitivity of the inherent
entrapment sensor. Available settings are
1-9 with 9 being the least sensitive.
N/A
SS 0
IES STOP ONLY
(Not used in
StrongArm models
0 = (off) Stop and reverse for 2s
1 = (on) stop only
A setting of 0, stops the gate and then
reverses its direction of travel for 2 seconds.
To stop gate travel with no reversal, the
optional setting 1 can be selected if the
gate operator is at a Usage Class IV site and
assigned a UC 4 classication.
N/A
LC 0
LEAF DELAY CLOSE
0 = none
1 to 7
Only appears if the gate operator is set up as
a Primary or a Secondary. Available settings
are 1 to 7. Each numerical increment adds ½
second, to a maximum of 3 ½ seconds time
delay, before the operator activates when
commanded to close.
LO 0
LEAF DELAY OPEN
0 = none
1 to
Only appears if the gate operator is set up as
a Primary or a Secondary. Available settings
are 1 to 7. Each numerical increment adds
1/2 second (with a maximum of 3 1/2 seconds)
time delay following a command to open
before the operator activates.
RT 0 (60 SECS)
MAXIMUM RUN
TIME
0 = 60 Seconds max run
1 = 300 Seconds max run
Allows an optional setting of 300 seconds
if changed to [RT 1] as opposed to the
maximum run timer default setting of
60 seconds.
N/A
PO 0 (OFF)
PARTIAL OPEN
0 = none
7 to 99 seconds
Activates the partial open input and allows
an adjustable distance by setting the open
duration. The available time settings are 7 to
99 seconds. The default setting [PO 0] leaves
this input inactive.
Open Partial
#6
COM
To Next Page
