Hytera PT580 - Page 100

Service Manual
No. Ref. No. Print No. Part No. Description
132
L7504 T2B 3221505100010 Bead
133
Q7101 B3A 3409003000030 Transistor
134
Q7102 B1B 3505010000200 P-MOSFET
135
Q7105 B1A 3403008000140 BRT
136
Q7106 B1B 3403008000140 BRT
137
R7001 B1B 3001051520000 1.5KΩ
138
R7002 B2B 3001052700000 27Ω
139
R7003 B2B 3001052700000 27Ω
140
R7004 B2B 3001051530000 15KΩ
141
R7005 B2B 3001051530000 15KΩ
142
R7008 T1B 3001051030000 10KΩ
143
R7009 B1A 3001052220000 2.2KΩ
144
R7011 B2A 3001051030000 10KΩ
145
R7018 T1A 3001054730000 47KΩ
146
R7020 B2C 3001050000000 0Ω
147
R7021 B2C 3001050000000 0Ω
148
R7022 B2C 3001051530000 15KΩ
149
R7101 T2C 3001051030000 10KΩ
150
R7102 B4B 3001051030000 10KΩ
151
R7103 T2C 3001051030000 10KΩ
152
R7104 B4B 3001051030000 10KΩ
153
R7105 B3C 3001051030000 10KΩ
154
R7106 B2C 3001051030000 10KΩ
155
R7107 B1C 3001051030000 10KΩ
156
R7108 B1C 3001051030000 10KΩ
157
R7109 B1A 3001053310000 330Ω
158
R7110 B1B 3001051210010 120Ω
159
R7124 B3B 3001054720000 4.7KΩ
160
R7125 B3B 3001052230000 22KΩ
161
R7126 B1B 3001054720000 4.7KΩ
162
R7127 B1B 3001054720000 4.7KΩ
163
R7128 B1B 3001052230000 22KΩ
164
R7129 B1B 3001054720000 4.7KΩ
165
R7131 B3A 3001051040000 100KΩ
166
R7132 B3A 3001051520000 1.5KΩ
167
R7150 T2C 3001051030000 10KΩ
168
R7205 B2A 3001055640020 560KΩ
169
R7206 B2A 3001055630010 56KΩ
170
R7208 B3A 3001064720000 4.7KΩ
171
R7209 B3A 3001054730000 47KΩ
172
R7213 B3A 3001051030000 10KΩ
173
R7233 B3A 3101051040060 0.1UF
174
R7234 B3A 3101051040060 0.1UF
175
R7236 B3C 3001050000000 0Ω
