Hytera PT580 - Page 101

Service Manual
No. Ref. No. Print No. Part No. Description
176
R7237 B3C 3001050000000 0Ω
177
R7238 B3C 3001050000000 0Ω
178
R7240 B3A 3001051010010 100Ω
179
R7241 B3A 3001051010010 100Ω
180
R7251 B1A 3001052220000 2.2KΩ
181
R7252 T1C 3001050000000 0Ω
182
R7259 B3B 3001051000000 10Ω
183
S7122 B1B 4301080000020 Momentary contact switch
184
U7002 B2C 3608010000070 Power management IC
185
U7201 B3A 3602010000010 Audio amplifier
186
U7202 B3B 3616093000000 Analog switch
187
U7203 B2B 3616093000000 Analog switch
188
U7204 B2B 3609009002460 ESD protection diode
189
U7205 T1C 3805000000020 EMI filter
190
U7206 T2B 3609009002460 ESD protection diode
191
U7207 B2B 3609009002460 ESD protection diode
192
U7208 T2B 3609009002460 ESD protection diode
193
U7209 B1A 3805000000020 EMI filter
194
U7210 B1A 3616093000000 Analog switch
195
U7211 B2A 3609026000970 LDO
196
U7215 B3B 3616093000000 Analog switch
99
