Hytera PT580 - Page 97

Service Manual
PT580 F5 Parts List 2 (MMI Board)
No. Ref. No. Print No. Part No. Description
1
B7203 B3B 5202002100200 Board-to-wire connector
2
C7001 B3C 3101051040060 0.1UF
3
C7002 B3C 3101051040060 0.1UF
4
C7004 B1B 3101064750010 4.7UF
5
C7005 B2B 3101051010030 100PF
6
C7006 B2B 3101051010030 100PF
7
C7007 B2A 3101051010030 100PF
8
C7008 T1C 3101051010030 100PF
9
C7009 T1C 3101051010030 100PF
10
C7010 T1C 3101051010030 100PF
11
C7011 B2A 3101051050160 1UF
12
C7012 B2A 3101051030020 0.01UF
13
C7013 B2A 3101062250000 2.2UF
14
C7014 B1A 3101051040060 0.1UF
15
C7017 B2C 3101064740000 0.47UF
16
C7018 B2B 3101061050020 1UF
17
C7019 B2C 3101064740000 0.47UF
18
C7020 B2B 3101061050020 1UF
19
C7022 B2C 3101061050020 1UF
20
C7023 B2C 3101061050020 1UF
21
C7051 B3C 3101064750010 4.7UF
22
C7052 B3C 3101064750010 4.7UF
23
C7055 B4A 3101053300000 33PF
24
C7056 B3A 3101053300000 33PF
25
C7060 T2B 3101053300000 33PF
26
C7061 B3B 3101053300000 33PF
27
C7062 T2C 3101053300000 33PF
28
C7063 B4B 3101053300000 33PF
29
C7064 T2C 3101053300000 33PF
30
C7065 B3B 3101053300000 33PF
31
C7066 B3A 3101053300000 33PF
32
C7067 B3B 3101053300000 33PF
33
C7068 B3A 3101053300000 33PF
34
C7069 B3B 3101053300000 33PF
35
C7070 B3A 3101053300000 33PF
36
C7071 B4B 3101053300000 33PF
37
C7072 B3B 3101053300000 33PF
38
C7102 B1B 3101051040060 0.1UF
39
C7103 B2C 3101051040060 0.1UF
40
C7114 B3A 3101064750010 4.7UF
41
C7115 T2B 3101051040060 0.1UF
42
C7116 B3B 3101053300000 33PF
43
C7124 B1B 3101061050020 1UF
