Hytera PT580 - Page 98

Service Manual
No. Ref. No. Print No. Part No. Description
44
C7201 B3A 3101051010030 100PF
45
C7202 B3A 3101051010030 100PF
46
C7203 B2C 3101082260020 22UF
47
C7204 B2A 3101061050020 1UF
48
C7205 B3A 3101051010030 100PF
49
C7206 B3A 3101051010030 100PF
50
C7207 B2B 3101051040060 0.1UF
51
C7208 B2B 3101064750010 4.7UF
52
C7210 B1B 3101082260020 22UF
53
C7211 B1B 3101051010030 100PF
54
C7214 B1A 3101054700010 47PF
55
C7215 B3B 3101051010030 100PF
56
C7216 B3B 3101051010030 100PF
57
C7217 B3B 3101051030020 0.01UF
58
C7218 B1B 3101082260020 22UF
59
C7219 B3B 3101051040060 0.1UF
60
C7221 T2C 3101054700010 47PF
61
C7222 B2A 3101082260020 22UF
62
C7223 B2A 3101061050020 1UF
63
C7224 B1B 3101051040060 0.1UF
64
C7225 B1B 3101051040060 0.1UF
65
C7254 T1C 3101051040060 0.1UF
66
D7103 B4C 3399040600010 ESD protection diode
67
D7104 B1A 3307120100050 LED
68
D7117 B1B 3399040600000 ESD protection diode
69
D7119 B1B 3399040600000 ESD protection diode
70
D7121 B1A 3399040600000 ESD protection diode
71
D7122 B1A 3399040600000 ESD protection diode
72
D7130 B1B 3303990000010 Switching diode
73
D7201 B1B 3399040600000 ESD protection diode
74
D7204 B3B 3399040600000 ESD protection diode
75
D7205 B3B 3399040600000 ESD protection diode
76
D7207 B2B 3399040600000 ESD protection diode
77
D7209 B1A 3399040600000 ESD protection diode
78
D7210 B2C 3399040600000 ESD protection diode
79
D7211 B1C 3399040600000 ESD protection diode
80
D7212 B1C 3399040600000 ESD protection diode
81
D7213 B2A 3399040600000 ESD protection diode
82
D7214 B2B 3399040600000 ESD protection diode
83
D7215 B1B 3399040600000 ESD protection diode
84
D7216 B1B 3399040600000 ESD protection diode
85
D7217 B2B 3399040600000 ESD protection diode
86
D7218 B2B 3399040600000 ESD protection diode
87
D7219 B2B 3399040600000 ESD protection diode
96
