Measurement is made from about 8 seconds after setting is done and will
continue measuring for 10 seconds.
●
Status display area of operation screen will display " Measuring" while
measuring.
●
The result of measurement is the sum of all network ports.
●
The result of measurement is only for reference. It may differ depending on
the network environment.
●
All other operations such as recording and playback will stop when the
"HDD management" page is displayed.
●
Displaying the "HDD management" page forcibly logs out any other users
currently logged in to the recorder.
[Terminal output test]
Outputs a signal from ALARM/CONTROL connector on the rear panel of the recorder.
Terminal: Selects the terminal at which to output the signal.
Test output duration: Select the duration over which the signal is output as 2 seconds, 5
seconds, or 10 seconds.
The signal will be output from the selected terminal when executed from the confirmation
screen that is displayed by clicking [Execute] button.
Manage the hard d isk d rives [HDD manageme nt]
The operations relating to the hard disk drives such as checking the capacity of each
recording area and formatting the drives can be performed on the "HDD management"
page of the setup menu - the "Advanced setup" menu.
How to display the "HDD management" page
STEP1
Click the [HDD management] button of the setup menu - the "Advanced setup" menu.
→
The window with the administrator name and password entry fields will be displayed.
The window is also displayed when a user has already logged in as the administrator.
STEP2
[Setup via recorder's main monitor]
158
