Images can be played on 1-screen and 4-screen in the control screen.
●
Images can be played back on 1-screen to 4-screen in the wide view.
●
The audio of the displayed image is output on 1-screen display and the
audio of the selected camera is output on multi-screen display of the
control screen.
●
The audio of the top-left camera on the screen is output during the wide
view.
●
No audio will be output when playing back in fast forward/fast reverse.
●
The camera image can be changed by clicking the camera number (1 to n)
during playback.
●
The Multiscreen select button, digital zoom button, Mute button and OSD
button remain effective during playback. Refer to the following section for
further information
☞
Monitor live images
●
Different values selected for resolution and frame rate will cause the data
size of the playback images on the multiscreen to differ considerably,
which may result in non-synchronized playback. In this case, pause and
then restart playback.
☞
Playback operation panel
●
At the default, black zones will be displayed on the top and bottom of
images with the aspect ratio of 16:9 when images are played back on the
control screen. Refer to the following section for the setting to enlarge the
vertical size of displayed images.
☞
Set up the main monitor [Main monitor]
●
Image with an aspect ratio of 16:9 is displayed fitting into the screen when
the image is played in wide view.
●
When using a 4K-compatible monitor, also refer to "Restrictions when
using this product"
Restrictions when using this product
When images recorded at a frame rate exceeding the following values are displayed on
each segment of a multiscreen, they will be played back according to the refresh interval at
the time of recording.
[Operation via recorder's main monitor]
277
