27
2. Specification
RCP2CR-SA7C
0
0 100 200 300 400 500 600 700
5
10
15
20
25
30
35
0 100 200 300 400 500 600 700
0
3
6
9
12
15
18
2
1
4
11
10
5
0
0 100 200 300 400 500 600 70
5
10
15
20
25
30
35
3
0 100 200 300 400 500 600 70
0
2
4
6
8
10
12
14
10.5
RCP2CR-SS7C
Payload (kg)
Payload (kg)
Payload (kg)
Speed (mm/s)
Speed (mm/s)
Vertical
Horizontal
Vertical
Horizontal
Lead 4
Lead 8
Lead 16
Lead 4
Lead 8
Lead 16
Lead 3
Lead 6
Lead 12
Lead 3
Lead 6
Lead 12
Speed (mm/s)
Speed (mm/s)
Payload (kg)
It is the payload when operating with the rated
acceleration below:
Lead 4
Rated acceleration : 0.2 G, when horizontal,
0.2 G when vertical
Lead 8
Rated acceleration : 0.3 G, when horizontal,
0.2 G when vertical
Lead 16
Rated acceleration : 0.3 G, when horizontal,
0.2 G when vertical
It is the payload when operating with the rated
acceleration below:
Lead 3
Rated acceleration : 0.2 G, when horizontal,
0.2 G when vertical
Lead 6
Rated acceleration : 0.3 G, when horizontal,
0.2 G when vertical
Lead 12
Rated acceleration : 0.3 G, when horizontal,
0.2 G when vertical
