while you press the buttons on the front panel. If you do not press any
buttons within 60 seconds, the menu changes to display the charging progress.
You can switch the front panel display to the menu at any time by pressing
the select button again.
5. Press and release the up or down button until the Node: option is displayed
on the first line of the front-panel display.
6. Verify that the node number that is displayed on the second line of the
front-panel display is the same as the node number that is printed on the
front panel of the node. Figure 101 shows how the node number appears on
the front panel.
7. Press and release the up or down button until the Ethernet option is shown
on the front panel display. The second line of the front-panel display in
Figure 102 shows the message Inactive. This message indicates that, although
an Ethernet connection is available, it cannot yet be used.
8. Press and release the up or down button until the FC Port-1 option shows in
the display.
9. Check whether the second line of the front-panel display shows the message
Active. If Active is not shown on the second line, go to “MAP 5600: Fibre
channel” in the IBM System Storage SAN Volume Controller: Service Guide to
repair the fault.
10. Press and release the left or right button to display the other port options.
Check whether for each port, the second line of the front-panel display shows
the message Active. If Active is not shown for any port, go to “MAP 5600:
Fibre channel” in the IBM System Storage SAN Volume Controller: Service Guide
to repair the fault.
11. If the configuration data table provided by the user indicates that the SAN
Volume Controller nodes are to be operated at 1 Gbps, follow these steps:
a. Press and hold the down button.
b. Press and release the select button.
c. Release the down button.
The
second line of the front-panel display shows the current fibre-channel
speed setting of the node. Press the up or down button until 1 Gbps is
displayed and then press the select button. This changes the fibre-channel
speed for all ports on this node to 1 Gbps.
12. If you want to select a language other than English, perform the following
steps:
a. Press the up or down button until Select Language? is displayed.
b. Press the select button.
Node:
xxxxxx
Figure 101. Node number
Ethernet:
Inactive
Figure 102. Ethernet mode
138 IBM System Storage SAN Volume Controller: Hardware Installation Guide
