Identifying system board components
111
Adding and removing hardware
Number Description Number Description
BT1
System battery
CN12
Diskette drive
connector
CN1
USB connectors
CN13
Joystick/MIDI, line-
in, line-out, and
mic-in connectors
CN2
Power switch (pins
10,20) and front-
panel LED (pins 4,
5,6,7:HDD LED,
pins 1,2,3: power
LED) connectors
CN14
Fax, voice, modem
connector
CN3
PS/2 mouse and
keyboard
connectors
CN15
CD-ROM audio
connector
CN4
ATX power
connector
DIMM 1,
DIMM 2
System memory
module sockets
CN5
ATI Multimedia
Channel (AMC)
feature connector
FN1
2-pin power supply
fan connector
CN6
Parallel, serial, and
VGA connector
SL1
PCI adapter card
connector
CN9
Modem ring-in
connector
SL2, SL3
ISA adapter card
connectors
CN10
Secondary IDE
connector
U27
Processor
CN11
Primary IDE
connector
66xarg.book : 66xach6.fm Page 111 Tuesday, June 30, 1998 10:18 AM
