Using the front panel display
The front panel displays icons and text that provide library, drive, and tape status
information. It also uses text prompts and warnings to guide you while making
changes.
The soft-key labels vary between screens. Use the key immediately below the label
to execute the desired function. The home screen below displays the following
information:
1
3
2
4 5 6 7 8
«1¬ Statement indicating general condition of the library.
«2¬ Drive and tape status (only for actual drives installed)
«3¬ Tape bar code (if applicable)
«4¬ Main option to go to the Information, Operations, and Administration menus
«5¬ Icon option to display the icons with a description (see“Panel Icons
messages” on page 21); also contains contrast adjustment
«6¬ Drive option to display additional information about the library drives
«7¬ Mail option to access the mailslot
«8¬ Map option to access information about the drive and tape slots
20 LTO Library: User’s Guide
