Panel Icons messages
The status bar can display the following icons to describe library and drive status.
The status bar is not available on the Home screen.
Power is off Online
Full and idle
Unloading a tape
Seeking data on a
tape
Writing data to a
tape
Failed, offline
Failed, online
Offline
Needs to be cleaned
Tape is cleaning a
drive
Rewinding a tape
Reading a tape
Erasing a tape
Tape is write
protected
Loading a tape
Empty
Library icons
Library status - failed
Library status - healthy
Library status -
partially available
Menu Command Nesting
Each level of the password-protected menus (Administration and Service) includes
all options available in the subordinate menu. For example, all options available in
the Administration Menu are also included in the Service Menu. This
functionality reduces the need to return to the Main Menu or re-enter the
password. The following figure displays the top level menu items and their
corresponding nested submenus.
Note: The front panel display returns to the Home screen if a button is not pressed
for 3 minutes.
Chapter 2. Operation 21
