5. Lay the connector assembly to the side, allowing the external cables to hang
from the connections. Do not disconnect external cables from the connector
plate.
6. Loosen the top and bottom thumbscrews on the drive module
7. Using the handle that is mounted on the back of the drive module, pull the
drive module straight out with one hand while supporting the bottom of the
drive module with the other hand.
Attention: To avoid injury, do not insert your hand or foreign objects through the
empty drive bay and into the vertical lift assembly area.
Installing a drive module
Follow these directions to install a drive module in the library.
Note: It is not necessary to turn off the library when inserting a replacement drive
module.
Follow these directions to install a drive module in the library.
1. Hold the drive module with one hand on the drive module handle and the
other hand supporting the bottom of the drive module.
2. Install the drive by inserting the rail at the top of the drive module into the slot
at the top of the drive module opening.
Note: Higher force will be required in the last half-inch of insertion to engage
the electrical connection.
3. Tighten the top and bottom thumbscrews, securing the drive module into the
library.
34 LTO Library: User’s Guide
