Replacing remote management card
To replace the remote management card, do the following:
RMC
To remove the remote management card, do the following:
1. Note the front panel configuration settings so that after you download
firmware, you can reset the library configuration settings.
2. Note how the library is connected, and remove all external cables attached to
the remote management card.
3. Loosen the two thumbscrews at the top of the card with a screwdriver or by
hand.
4. Remove the card by gently pulling it straight out from the library.
To replace the remote management card, do the following:
1. Align the top and bottom edges of the card with the recessed slots on the left
side of the library.
2. Gently slide the card to the back slot, ensuring that the card aligns with the
internal guide tracks.
3. Ensure that the front of the card is flush with the library, and tighten the
thumbscrews.
4. Turn on the library.
5. Configure the library.
Replacing power supply
A failing power supply disables the library. A failing power supply on upper levels
of Models 4/40 and 6/60 results in a partial availability state. When the library is
in a partial availability state, it is still functional, but is not in optimum
configuration. When this occurs, the front panel will display Partially Available,
and the illuminated bar beneath the front panel display will be solid amber until
the condition is resolved.
To remove the power supply, do the following:
1. Power off the library.
2. Disconnect the power cord from the back of the power supply.
3. Loosen the thumbscrews at the top and bottom of the power supply. If the
thumbscrews are too tight to loosen by hand, loosen them with a screwdriver.
4. Grasp the handle on the back of the power supply with one hand and pull
outward. Support the bottom of the power supply to avoid dropping the
module.
36 LTO Library: User’s Guide
