Chapter 4. IBM System Storage DS planning and configuration 211
3. The next window allows you to select the logical drives that are going to be mapped to the
host or the group. You also have to specify a LUN for each logical drive. In our example,
shown in Figure 4-77, we selected WindowsLD1 and WindowsLD2. We assigned the
LUNs 0 and 1, respectively, to these two logical drives.
Figure 4-77 Storage Partitioning wizard: Selecting logical drives/LUNs
4. Click Finish when you are done with selecting the logical drives and assigning the LUNs.
5. Display your newly defined host groups, host, and mappings by selecting the Mappings
view in the Subsystem management windows, as shown in Figure 4-77.
Figure 4-78 Displaying created mappings
