Table 8. Parts listing for 4U server models with non-hot-swap power supplies, Type 2582. For the 5U server model
with hot-swap power supplies (Model name: 2582-F4x), please see Table 9. (continued)
Index Description
CRU part
number
(Tier 1)
CRU part
number
(Tier 2)
FRU part
number
EMC shield 49Y8455
Filler, DVD-ROM Drive 13N2450
Filler, PCI card 81Y7472
Hardware, misc. 81Y7475
ServeRAID-BR10il v2 SAS/SATA controller 49Y4737
ServeRAID M5015 SAS/SATA Controller (Battery not
included)
46C8927
ServeRAID M5025 SAS/SATA Controller 46C8929
ServeRAID M1015 SAS/SATA Controller 46C8931
ServeRAID M5014 SAS/SATA Controller (Battery not
included)
46C8933
System service label 81Y7480
Shield kit 13N2997
Shield kit, simple-swap 3.5- inch hard disk drive 81Y7479
Tower to rack kit assembly 00D4255
Friction slide 69Y4391
NetXtreme I Quad Port Adapter 90Y9355
NetXtreme I Dual Port Adapter 90Y9373
QLogic 10Gb Dual-Port CNA 00Y3274
6Gb Performance Optimized HBA 46C8937
Recovery Package M3 Management Node with Software
Preload DVD
00D7763
Internal USB 3 RDX carrier/dock 46C2346
Internal USB RDX carrier/dock 46C5380
6Gb SAS HBA 46C8935
SFP optical module 46C9297
3U BRACKET KIT 94Y7628
The following illustration shows the major components in the 5U server model with
hot-swap power supplies (Model name: 2582-F4x). The illustrations in this
document might differ slightly from your hardware. For 4U server models with
non-hot-swap power supplies, please see Table 8.
154 IBM System x3100 M4 Type 2582: Problem Determination and Service Guide
