IBM System x3100 M4 Problem Determination And Service Guide

Table 9. Parts listing for the 5U server model with hot-swap power supplies (Model name: 2582-F4x). For 4U server
models with non-hot-swap power supplies, please see Table 8. (continued)
Index Description
CRU part
number
(Tier 1)
CRU part
number
(Tier 2)
FRU part
number
14 Microprocessor, Xeon E3-1270 3.4GHz 4C 8MB cache 69Y5149
14 Microprocessor, Xeon E3-1280 3.5GHz 4C 8MB cache 81Y6933
14 Microprocessor, Xeon E3-1220 3.1GHz 4C 8MB cache 81Y6945
14 Microprocessor, Xeon E3-1230 3.2GHz 4C 8MB cache 81Y6947
14 Microprocessor, Xeon E3-1260L 2.4GHz 4C 8MB cache 81Y6949
14 Microprocessor, Xeon E3-1220L 2.2GHz 2C 3MB cache 81Y6951
14 Microprocessor, Pentium G850 2.9GHz 2C 3MB cache 81Y7504
14 Microprocessor, Xeon E3-1220v2 3.1GHz 4C 8MB cache 00D8552
14 Microprocessor, Xeon E3-1270v2 3.5GHz 4C 8MB cache 00D8553
14 Microprocessor, Xeon E3-1280v2 3.6GHz 4C 8MB cache 00D8554
14 Microprocessor, Xeon E3-1240v2 3.4GHz 4C 8MB cache 00D8555
14 Microprocessor, Xeon E3-1230v2 3.3GHz 4C 8MB cache 00D8556
14 Microprocessor, Xeon E3-1265L v2 2.5GHz 4C 8MB
cache
00D8557
14 Microprocessor, Celeron G440 1.6GHz 1C 1MB cache 94Y6303
14 Microprocessor, Core i3-2120 3.3GHz 2C 3MB cache 99Y1447
14 Microprocessor, Pentium G870 3.1GHz 2C 3MB cache 00D8899
14 Microprocessor, Pentium G860T 2.6GHz 2C 3MB cache 00D8900
14 Microprocessor, Pentium G640 2.8GHz 2C 3MB cache 00D8901
14 Microprocessor, Pentium G640T 2.4GHz 2C 3MB cache 00D8902
14 Microprocessor, Pentium G550 2.6GHz 2C 2MB cache 00D8903
14 Microprocessor, Pentium G540T 2.1GHz 2C 2MB cache 00D8904
15 Heat sink 81Y7493
Battery, 3.0 volt 33F8354
Hard disk drive cage, 2.5" drives 00D8852
Cable, SAS signal (2.5" hot-swap hard disk drive) 00D2814
Cable, backplane configuration (2.5" hot-swap hard disk
drive)
00D8850
Cable, power supply interposer 00D8861
Cable, optical disk drive/tape drive 25R5635
Cable, USB conversion 39M2909
Cable, 1m SAS 39R6530
Cable, 3m SAS 39R6532
Cable, 1m internal USB 44E8893
Cable, internal USB 81Y3643
Feet, chassis 13N2985
EMC shield 49Y8455
Filler, DVD-ROM Drive 13N2450
156 IBM System x3100 M4 Type 2582: Problem Determination and Service Guide

IBM System x3100 M4 Specifications

General

Memory	Up to 32 GB DDR3 ECC UDIMM
Memory Slots	4 DIMM slots
Form Factor	Tower
Chipset	Intel C202
Processor Sockets	1
Processor	Intel Xeon E3-1200 v2 series, Intel Pentium series, Intel Celeron series
Storage	Up to 4x 3.5-inch
Power Supply	350W
Hard Drive Bays	4 x 3.5"
RAID Support	RAID 0, 1, 10
Network Interface	Gigabit Ethernet
Expansion Slots	1 x PCIe 3.0 x16, 1 x PCIe 2.0 x4
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
