IBM System x3100 M4 Problem Determination And Service Guide

Table 6. IMM2 error messages (continued)
v Follow the suggested actions in the order in which they are listed in the Action column until the problem
is solved.
v If an action step is preceded by “(Trained technician only),” that step must be performed only by a trained
technician.
806f0108-0a01xxxx
806f0108-0a02xxxx
The Power Supply n
has failed. (n = power
supply number)
Error Power supply n
has failed. (n =
power supply
number)
1. Reseat power supply n.
2. If the power-on LED is not lit and
the power-supply error LED is lit,
replace power supply n.
3. If both the power-on LED and the
power-supply error LED are not lit,
see “Power problems” on page 90
for more information.
(n = power supply number)
806f0308-0a01xxxx
806f0308-0a02xxxx
The Power Supply n
has lost input. (n =
power supply number)
Info Power supply n AC
has lost. (n =
power supply
number)
1. Reconnect the power cords.
2. Check power supply n LED.
3. See “Power problems” on page 90
for more information.
(n = power supply number)
806f0608-0a01xxxx Power Supply 1 has a
configuration mismatch.
Error A power supply
with a
configuration error
has been
detected.
1. Reseat the power supply, and then
restart the server.
2. Replace the power supply n.
(n = power supply number)
806f0608-0a02xxxx Power Supply 2 has a
configuration mismatch.
Error A power supply
with a
configuration error
has been
detected.
1. Reseat the power supply, and then
restart the server.
2. Replace the power supply n.
(n = power supply number)
800b0108-1301xxxx Power Unit redundancy
lost has asserted.
Error Redundancy has
been lost and is
insufficient to
continue operation.
1. Check the LEDs for both power
supplies.
80010002-0701xxxx Numeric sensor Planar
VBAT going low (lower
non-critical) has
asserted.
Warning A lower critical
sensor going low
has asserted.
Replace the system battery (see
“Removing the system battery” on
page 207 and “Installing the system
battery” on page 209).
80010202-0701xxxx Numeric sensor Planar
VBAT going low (lower
critical) has asserted.
Error A lower critical
sensor going low
has asserted.
Replace the system battery (see
“Removing the system battery” on
page 207 and “Installing the system
battery” on page 209).
80010902-0701xxxx Numeric sensor Planar
3.3V going high (upper
critical) has asserted.
Error An upper critical
sensor going high
has asserted.
(Trained service technician only)
Replace the system board (see
“Removing the system board” on page
258 and “Installing the system board”
on page 261).
80010202-0701xxxx Numeric sensor Planar
3.3V going low (lower
critical) has asserted.
Error A lower critical
sensor going low
has asserted.
(Trained service technician only)
Replace the system board (see
“Removing the system board” on page
258 and “Installing the system board”
on page 261).
Chapter 3. Diagnostics 41
