PANEL DESCRIPTION
■ HM-182 front and top panels (Continued)
r O•G•P/RS KEY
O࡮G࡮P
RS
N (Scan Mode/Rpt Scan)
➥ Push to select the scan type from open scan, group
scan and priority scan in order. (pgs. 23, 24)
• “ ” appears when the open scan is selected, “ ” ap-
pears when the group scan is selected, and “ ” appears
when the priority scan is selected.
➥ Push and hold for 2 sec. to start the repeater scan.
(p. 25)
• Repeater output channels are between ‘CB-R1’ to ‘CB-R8’
operation only
F (Quiet/ID-MR)
➥ Push to toggle the quiet function ON or OFF. (‘CB-XX’
displays when the CB channel is selected.) (p. 33)
• “Q” appears when the quiet function is turned ON.
➥ Push and hold for 2 sec. to enter the received ID code
history indication mode. (p. 32)
• “NO ID” is displayed when no ID code is memorised.
t LOW/“ ” KEY
LOW
N (RF Power/Lock)
➥ Push to toggle the transmit output power level. (p. 15)
➥ Push and hold for 2 sec. to electronically lock all keys
except the following. (p. 18)
[PTT],
MONI
TSQL
(Monitor),
F
SET
(Function),
SCAN
TAG
(Call),
(Loud), (Small) and
LOW
(Lock).
• “ ” appears when the lock function is ON.
• Push and hold for 2 sec. again to turn the lock func-
tion OFF.
F (Dup/Zone)
➥ Push to toggle the selected channel between duplex
or simplex operation (Depending on pre-setting).
• Duplex operation can be selected within ‘CB-R1’ to ‘CB-R8’
only.
➥ Push and hold for 2 sec., then select the desired zone
with
or . (p. 15)
• Available only when more than two zones are set.
PRIO
LOW
SCAN
O࡮G࡮P
CH
SET࡮P
RS
TAG
SQL
q
w
e
Speaker
Microphone
r
t
y
u
i
MONI
F
SET
TSQL
o!0 !1
