Icom IC-440 - 3 Basic Operation; Turning Power on; Volume Selection; Channel Selection

■ Turning power ON
q Push and hold for 2 sec. to turn the power ON.
w If the transceiver is programmed for a start up password,
input the digit codes as directed by your dealer.
• The keys in the table below can be used for password input:
• The transceiver detects numbers in the same block, as identi-
cal. Therefore “01234” and “56789” are the same.
e When the “PASWD” indication does not clear after input-
ting 4 digits, the input code number may be incorrect. Turn
the power off and start over in this case.
■ Volume selection
➥ Push or to select the desired volume level.
• “ ” appears when volume level 0 is selected (while the internal
speaker is muted).
■ Channel selection
➥ Push
CH
SQL
to enter the channel selection mode, then push
or to select the desired channel.
• While pushing and holding or , the displayed channel
changes continuously until channel 1 is selected.
• When channel 1 is selected, beeps are emitted.
• ‘CB-XX’ appears when the CB channel is selected and ‘RX-XX’
appears when the RX channel is selected.
• “
” appears when channel selection mode is selected.
14
3
BASIC OPERATION
KEY
NUMBER
0
5
4
9
3
8
2
7
1
6
MONI
F
SET
TSQL
PRIO
LOW
SCAN
O࡮G࡮P
CH
SET࡮P
RS
TAG
SQL
[PWR]
O࡮G࡮P
RS
SCAN
TAG
PRIO
SET࡮P
LOW
O࡮G࡮P
RS
SCAN
TAG
PRIO
SET࡮P
LOW
Appears
